Efficient Cooling Technology
Internationally-recognized high-end compressors and titanium coaxial heat exchangers provide high performance, low energy consumption and low noise levels.
Intuitive controller with accurate temperature detection from 32 to 95°F. Closed loop temperature control system with extremely tight differential of 1°F. Displays in °F or °C, and audible alarms for certain situations.
Solid and durable structure designed to guarantee near perfect protection against corrosion. Rotatable in-set water connections, rotatable exhaust conveyor, and smaller form-factor helps facilitate placement of chiller in confined spaces.
Ability of the TANK TK-500 to pull down water temperatures in an 86°F room:
AQUARIUM SIZE TEMP. ATTAINABLE HEATING LOAD NET PULL-DOWN C.O.P.* 130 gallons 77°F from 86°F 1.89 watts/gal. 9°F cooler 2.0
* Coefficient of Performance (COP) - a numerical value that represents cooling performance from a baseline room temperature of 86°F and a typical heat source (aka. Heating Load
Heater is pre-installed and included in the price of this unit.This unit does not accept the UV Sterilizer Kit like its equivalent TR/TC predecessor.
The 400w heater kit is designed to work universally with all Teco SeaChill Aquarium Chillers. Installation is easy and takes less than 10 minutes. No tools required. Includes an installation guide.
Optional Air Conveyor Extension Kit (Available as an add-on purchase.)
A kit of two modular extensions designed to extend the opening of the top-side rotating conveyor on TK-500, TK-1000 and TK-2000 aquarium chillers. Chillers can overheat when placed inside a cabinet or confined space, resulting in decreased performance, increased energy utilization, and permanent damage to internal components. These extensions can be used to help channel heat further away from the chiller's operating environment. Extensions can also be mounted to the sides of cabinets using the pre-marked holes as a guide.
Each extension is modular and extends the conveyor's vent in 2 inch increments (up to 4 inches per kit).
Optional Flow Indicator (Available as an add-on purchase)
The TECO Flow Indicator is an important accessory for most aquarium system setups. Connect the Flow Indicator to any pipe or tubing that water flows through. The red fan in the middle will spin--a visual indication that water is presently flowing. The Flow Indicator can also be used to "join" tubes or pipes together.
- Recommended Aquarium Size: Up to 120 Gallons
- Horsepower: 1/6HP
- Minimum Flow Rate: 106 gph
- Maximum Flow Rate: 211 gph
- In/Out Water Connection: 3/4" Tube Diameter
- Exchanger: Titanium
- Supply: 115V-60Hz
- Power Consumption: 225 Watt
- Gas/Refrigerant: R134A
- Weight: 36.4 lbs. (16.5kg)
- Dimensions: 12.2"x12.2"x16.38"
- Additional Information
- Product Specs
Manufacturer SEACHILL (TECO)
This is a quality peace of equipment and runs extremely quiet.
Although all the reviews claim that the hysteresis spread can only be 1 degree; this is incorrect. I set the temp in my tank to 77 and the Hy to .5 degrees and it starts up at 77.5 degrees.
The unit works great!
